BDCOM WiFi XPON ONU GP1704-4GV-22A DUAL BAND SUPPORT

The BDCOM GP1704-4GV-22A subscriber terminal is made in a plastic case, on the front panel there is a PON port with an SC/UPC connector, 4 Gigabit Ethernet ports, 2 POTS ports, a USB port and a connector for connecting a power adapter, on the rear panel there are four Wi-Fi antennas.

This device can operate in both EPON and GPON networks.

GPON: Supports PON data rate downlink 2.5Gbps/uplink 1.25Gbps.

EPON: Supports PON data rate of 1.25Gbps downlink, 1.25Gbps uplink.

Wi-Fi frequencies: 2.4 GHz, 5 GHz.

Network coverage radius - 20 km.

The subscriber terminal supports DBA and Rate-Limit.

Functional Parameters

Interfaces 4*GE

WiFi (802.11b/g/n+802.11ac) four antennas

1 USB port (USB2.0)

2 VoIP ports (FXS - RJ11)

WIFI 1200 Mbps 2.4/5Ghz

PON interface Data transfer rate, Gbps:

2.5 (downstream) / 1.25 (upstream)

Network coverage radius 20 km

PON port type: SC / UPC

Optical receiver sensitivity: ≤- 28 dB

Radiated power: 0.5 ~ 5 dB

Security: ONU authentication mechanism

Standards ITU-T G.984/G.988

PRC Community Industry

Standard GPON ONU in Access

Technology Requirements

IEEE 802.1D, Spanning Tree

IEEE 802.1Q, VLAN

IEEE 802.1w, RSTP

ITU-T Y.1291

VLAN 4K VLAN

Port based VLAN

IEEE 802.1Q VLAN

CTC2.0 defined VLAN

Multicast IGMP-Snooping

CTC defines dynamic multicast

MLD-Snooping

QoS Backpressure flow control (half duplex)

IEEE 802.3x flow control (full duplex)

Head Of Line (HOL) mechanism

IEEE 802.1p, CoS

Four priority queues on each port

WR, SP and FIFO

Rate limiting

Reliability

Dying-Gasp

TX/RX optical power alarm loop detector

Safety Limiting the number of MAC addresses on a port

Port Security

Port storm control

Port scan prevention

DOS attack prevention

WiFi 802.11b/g/n/ac, 1200Mbps, 2x2 MIMO

Multi SSID

SSID encryption

Voice functions (VoIP) SIP, H.248

Control CLI, Web, SNMP, TR069 and TELNET

Software upgrade via TFTP, WEB, TR069 or OMCI

Local syslog or server syslog

Dimensions mm (W x D x H) 230 x 140 x 34.9

Environmental requirements Working environment: 0℃～45℃; 10%～90% humidity (non-condensing)

  Storage conditions:-4 0℃ ～80℃;5% ～95% humidity (non-condensing)

Power supply DC12V/1A (external adapter power supply)

Power consumption 15 W

Weight 0.4 kg
